Overview

Features & Construction

  • Designed to look like a recessed can light
  • Quiet operation 1.2 Sones
  • PCRL80 has an E26 bulb base (bulb sold separately)
  • PCRL80F has a GU24 bulb base (CFL spiral bulb included)
  • Enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on
  • Galvanized housing with black polyester powder coat finish
  • Universal 4 or 5" metal duct adaptor with built-in backdraft damper
  • 14-24" adjustable hanging bars
  • Fits 2x8 construction

Certifications & Listings

Please see the Submittal of each PCRL model for the certified performance data.

  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)

Applications

  • Residential Bathroom Exhaust
    Improve IAQ by removing excess humidity, odors, and VOC's from the residential bathroom.
  • Commercial Bathroom Exhaust
    Improve IAQ by removing excess humidity, odors, and VOC's from the commercial bathroom.
  • Local Exhaust
    Local demand-controlled exhaust is intended to remove contaminants from kitchens and bathrooms.
  • Dwelling Unit Ventilation
    Exhaust air at a continuous rate to provide fresh air to the dwelling unit.

Product Specifications

HVI Performance Data

Part ID Duct (in) HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Frequency (Hz) Voltage (V) Efficacy @ 0.1" SP (CFM/Watts) Watts @ 0.1" SP Current (Amps)
PCRL80 4 & 5 80 50 1.5 60 120 4.1 19.7 0.27
PCRL80F 4 & 5 80 50 1.5 60 120 4.1 19.7 0.27

Dimensions

Dimensional drawing for the recessed vent light models.
Part ID W D H Avg. Ship Weight (lbs)
PCRL80 12.625 8 7.25 10
PCRL80F 12.625 8 7.25 10

Dimensions W, D, and H are displayed in inches and rounded to the nearest thousandth of an inch.

Options and Accessories

Light Cover Options

Image Description Literature
Image of light cover. PCRL80LC
Light Cover for use with PCRL80 when not using PAR30 style bulb.


Plug-&-Play Modules

Image Description Literature
Image of a humidity sensor Plug-&-Play option. PCHS
Humidity Sensor
SubmittalIOM
Image of a speed control Plug-&-Play option. PCSC
Speed Control
SubmittalIOM

Wall Control Options

Image Description Literature
Image of a 3-switch control. PC3S
3-Switch Control
Submittal
Image of a delay timer switch. FLTD-60
Fan/Light Delay Timer Switch
Submittal
Image of a rotary spring wound timer. SRT-30
Rotary Spring Wound Timer
Submittal
Image of a electronic push button timer. EPBT-60
Electronic Push Button Timer
Submittal
Image of a bathroom ventilation control. FT622
ASHRAE 62.2 Bath Fan Ventilation Control
Submittal
Image of a programmable fan timer. FT247
Programmable Fan Timer
Submittal

Accessories

Images Description Literature
Image of a plastic louvered shutter. PER-W
Plastic Louvered Shutter
Submittal
Image of a aluminum exterior fixed grille. GRA
Aluminum Exterior Fixed Grille
Submittal
Image of a roof curb. RC
Roof Cap
Submittal
Image of a round adjustable metal elbow. ME
Round Adjustable Metal Elbow
Submittal
Image of a duct connector. DC
Duct Connector

Image of a worm clamp. WC
Worm Clamp
